- Up to 50Gbps data rate per channel by PAM4 modulation - 4 duplex channels transmitters and receivers - Integrated CWDM LD and PD array - Duplex LC/UPC connecting interface compliant - Single +3.3V power supply 6, DDM function implemented - Hot-pluggable QSFP56 form factor - Maximum link length of 2km via SMF fiber - Low power dissipation:<6.5W - International class 1 laser safety certified - Operating temperature range: 0℃ ~ +70℃ - Compliant with ROHS
Send Inquiry

Product Description

✓
The 200G QSFP-200G-FR4-S QSFP56 FR4 Fiber Optic Transceiver is designed to transmit and receive optical data links 50 Gb/s bit rate per channel with PAM4 modulation format via up to 2km single mode fiber.
✓
Designed for high-speed, short-range data transmission, these modules meet various high-density network requirements.
✓
Utilizing 4 lanes at a rate of 50Gbps per lane over a wavelength of 1310nm to achieve a total bandwidth of 200Gbps.
✓
Features a hot-pluggable QSFP56 package with an advanced electrical interface employing high-speed differential signaling to minimize EMI.

Technical Specifications

CompatibilityCisco Compatible
ModelQSFP-200G-FR4-S
Form FactorQSFP56
Max Data Rate200Gbps (4x50Gbps)
Wavelength1310nm
Distance2km
ConnectorDuplex LC
Fiber TypeSMF (Single Mode Fiber)
Transmitter TypeDFB
Receiver TypePIN
DDM/DOMSupported
TX Power-4.2 ~ 4.7dBm
Mini Receiver Power-8.2dBm
Temperature Range0 to 70°C
Warranty1 Year

Quality Assurance & Testing

Comprehensive Testing Increases Reliability: Qualified through a rigorous process with advanced equipment to ensure you get high-quality and reliable optics.

Proven Interoperability: Every unit is quality tested in host devices for compatibility in targeted switch environments, guaranteeing flawless operations and seamless connectivity.

Applications

200GBASE-FR4 Ethernet

Ideal for high-speed Ethernet applications requiring 200G bandwidth.

Data Centers

Designed for intra-data center connectivity and high-density environments.

Switch & Router Connections

Enables reliable links between high-performance networking hardware.

Frequently Asked Questions
What is the transmission distance of the QSFP-200G-FR4-S?
This module supports data transmission over single-mode fiber (SMF) for distances up to 2km.
What type of modulation does this 200G transceiver use?
The 200G QSFP56 FR4 uses PAM4 (Pulse Amplitude Modulation 4-level) format with 4 channels of 50 Gb/s.
Is the module hot-pluggable?
Yes, it features a hot-pluggable QSFP56 package, allowing for easy installation and maintenance without powering down the system.
What fiber connector is required for this module?
The QSFP-200G-FR4-S is designed with a Duplex LC connector for use with Single Mode Fiber.
Does this transceiver support digital diagnostic monitoring?
Yes, DDM/DOM is supported, allowing real-time monitoring of parameters such as power, temperature, and voltage.
What environments is the 200G QSFP-200G-FR4-S best suited for?
It is ideal for 200GBASE-FR4 Ethernet, data centers, and high-speed switch or router interconnects.
